DF140B Outboard

DF140B Outboard

$0.00

Superseding the ever-popular DF115A and DF140A outboard motors, the new “B” series feature a host of updates, many of which are shared with the highly acclaimed DF115BG, and DF140BG Suzuki Precision Control (SPC) drive-by-wire outboard motors released in 2021, albeit in mechanically driven form.

The compression ratio has been increased from 9.7:1 to 10.6:1 to achieve greater top speed and acceleration produced by the 2.0-litre displacement inline four-cylinder engines. Lean Burn fuel efficiency has also been significantly improved compared to the outgoing “A” series models. Tests have demonstrated as much as 10% improvement across mid-range to high-end cruising speeds.

100 in stock

SKU: SOB-DF140B Categories: ,

Description

Superseding the ever-popular DF115A and DF140A outboard motors, the new “B” series feature a host of updates, many of which are shared with the highly acclaimed DF115BG, and DF140BG Suzuki Precision Control (SPC) drive-by-wire outboard motors released in 2021, albeit in mechanically driven form.

INCREASED COMPRESSION RATIO

The compression ratio has been increased from 9.7:1 to 10.6:1 to achieve greater top speed and acceleration produced by the 2.0-litre displacement inline four-cylinder engines. Lean Burn fuel efficiency has also been significantly improved compared to the outgoing “A” series models. Tests have demonstrated as much as 10% improvement across mid-range to high-end cruising speeds.

ADVANTAGE

  • Improved combustion results in greater fuel efficiency compared with “A” series models.
  • 10.6:1 Compression Ratio contributes to improved engine torque.

FEATURES

EASY MAINTENANCE

Specially designed to be easy for owners to perform maintenance tasks.

ADVANTAGES

Easy access oil filter:

  • Can be replaced simply by removing the top cover.

Oil Spill Catcher:

  • A tray is added around the oil filter to catch oil which comes out when exchanging the oil filter

Oil Level Gauge:

  • Able to use Φ15 oil changer hose

NEWLY DESIGNED AIR INTAKE SYSTEM

The air intake structure was reviewed and improved.

ADVANTAGE

  • Delivers higher power output.
  • Increased ability to remove water from air taken into cowl.
  • Decrease in the air intake temperature.

DIRECT IGNITION

Integrates the ignition coils into the spark plug caps.

ADVANTAGES

  • Reduces the number of parts and simplifies the wiring system.
  • Removing the high tension cord enables the ignition to generate spark efficiently which leads to the improvement of combustion efficiency.

WATER DETECTING SYSTEM

  • It helps to protect the engine from water in the fuel.
  • Using bigger fuel filter than the DF140A/115A.
  • Optimised Fuel Filter position.

ADVANTAGE

  • Can avoid water in fuel.
  • Increased Durability & Reliability.
  • Easy replacement of fuel filter.

MORE FEATURES TO CONTRIBUTE TO DURABILITY

Large capacity Fuel Pump:

  • Capable to rig on various kinds of boats

Optimized O₂ Sensor mounting position:

  • Increased Durability

Using Zinc-containing Rustproof Coating bolt:

  • Increased Durability

LEAN BURN CONTROL SYSTEM

The Lean Burn Control System supplies the optimal amount of fuel and air mixture depending on the navigation conditions.

ADVANTAGE

  • Significant improvement in fuel economy in all speed ranges especially at cruising speed.
  • Fuel is saved and petrol costs are greatly reduced thanks to the improved fuel economy.

OFFSET DRIVE SHAFT

The engine powerhead is positioned closer to the front, moving the outboard’s centre of gravity forward.

ADVANTAGE

  • Less vibration.
  • More compact.
  • Stable steering performance.

2-STAGE GEAR REDUCTION

This system which incorporates the Offset Driveshaft features a first stage reduction between the crankshaft and drive shaft, and a second stage reduction inside the gear case.

ADVANTAGES

  • High Torque even with big loads.
  • Powerful enough to rotate a larger propeller

QUIET OPERATION

Intake noise is suppressed with a resonator, resulting in quieter noise output.

ADVANTAGE

  • Less noise, making boating more enjoyable.

INCREASED ALTERNATOR OUTPUT

Newly designed ventilation which improves cooling around the coils.

ADVANTAGE

  • 3Amp higher alternator output at idle speed range that is roughly equivalent to the necessary output required to operate the SMD12/SMD16 displays.

IMPROVED GEAR CASE

By optimising the gear oil passage, the spinning pinion gear generates negative pressure and it helps gear oil circulation.

ADVANTAGE

  • It lowers gear oil temperature and contributes to the increased durability of pinion gear

SPECIFICATIONS

Recommended Transom Height L: 508mm, X: 635mm
Weight L: 186kg, X: 190kg
Valve Train DOHC 16-Valve
Displacement 2,045cm³
Maximum Output 103.0kW
Control System Mechanical
Recommended Fuel RON91 / AKI87
Alternator 12V 40A
Gear Ratio 2.59 : 1 (Two-stage gear reduction)
Exhaust Through Prop Hub Exhaust
Starting system Electric
Engine Type In-line 4 cylinder, 4-stroke
Fuel Delivery System Electronic Fuel Injection
Bore X Stroke 86 x 88mm
Full Throttle Operating Range 5,700 – 6,300rpm
Oil Pan Capacity 5.5L
Fuel Tank Capacity (L)
Trim Method Power Trim and Tilt
Gear Shift F-N-R
Propeller Selection (Pitch) 15” – 25” (R/R), 17” – 23” (C/R)
